QED Performance ultra High speed Active HDMI kabelis (7,5m - 20m)

QED Optical Ultra High Speed HDMI

The new Optical Ultra High Speed HDMI is our most advanced long cable yet.

Designed to transfer a maximum compressed video resolution of up to 48Gb/s 10K@120Hz and uncompressed 8K@60Hz over long cable runs of 7.5 to 20 metres in length. The perfect solution for modern day AV installations, this high-performance HDMI 2.1-certified cable can handle all current HDMI standards.

Engineering pedigree

QED has been designing and engineering superior analogue and digital cables for more than 45 years, and its new Performance Optical Ultra High Speed HDMI cable is informed by the results of the company’s exhaustive research into cable design since 1995.

Supports 8K and the latest HDMI standards

The perfect solution for modern day AV installations, this high-performance HDMI 2.1-certified cable can handle all current HDMI standards, including uncompressed 48Gb/s 8K@60Hz video resolution, Dolby Atmos audio and HDR (High Dynamic Range)* picture technology.

Technical Specifications

Full Compliance with 8K@60Hz 4:2:0 uncompressed resolutions. *Display Stream Compression for resolutions up to 10K@120hz (4:2:2)

Data transfer rates up to 48 Gb/s

Compatible with HDMI 2.1 standard: EDID, CEC, HDCP (2.2), HDR+ (High Dynamic Range), HEC, eARC

Backward compatible with HDMI 2.0/HDMI 1.4b

Triple-shielding further protects against interference for optimal signal quality

Ultra High Speed QR Code for peace of mind

Delivers dual video streams to compatible displays

Supports up to eight PCM channels, DTS-HD Master and Dolby Digital True HD surround sound audio

Delivers multi-stream audio to up to four users

Zinc-alloy HDMI connectors for enhanced durability and performance

OM3 fibre technology greatly reduces EMI/RFI emissions

Hybrid construction utilizes both fiber and copper

Extended temperature range from -40 to 70°C for installations in harsh environments or manufacturing floors

LSZH Jackets comply with Reaction to Fire Class CCA –s1, d0

Available in standard lengths 7.5 m, 10 m, 12 m, 15 m & 20 m

Source & Display clearly printed on the connector for easy identification

Has high pulling strength and compression load

Plug and Play, no external power required
